Induction Annealing Machine

Annealing is a heat treatment in which material is exposed to an elevated temperature and slowly cooled. Annealing of the material changes physical properties of the material such as strength and hardness.


Microtech induction annealing machines are designed to be used for Normalising, Stress relieving and Process Annealing.

Applications


  • Stress Relieving.
  • Post weld Annealing.
  • Shell Annealing.
  • Annealing of wires.
  • Annealing of Copper tubes.
  • Annealing of knife, blade ends.
  • Continuous Annealing of copper wires.
  • Annealing of brazing wires & Rods.
  • Stainless Steel / Aluminum Utensils
  • All Cold Formed Steel Components.
  • Annealing of Milk Cans, Oxygen cylinder for neck formation.

Features


  • Faster Annealing cycle.
  • Higher productivity.
  • Highest system efficiency.
  • Application Specific.
  • Auto or manual mode operation.
  • Highly adaptable for automation.
  • No statutory approvals required.
  • Uniform annealing with better quality end product.
  • Lesser Annealing cost comparing to conventional methods.
  • Eco-friendly due to noiseless and flameless operation.
  • Lesser risk involved compared to conventional methods.
  • Improved power factor.
  • Tropicalised design.
  • Compact size.

Specifications

In our Endeavour to make better products, Microtech Induction Pvt. Ltd. reserves the right to change any specifications at any moment and without prior notice, to the models (including programming) and their accessories.

POWER RANGE 1-5KW 5-15KW. 15-50KW 50 -200KW
FREQUENCY RANGE 5-600kHz 01-400kHz 01-30kHz 01 – 30kHz
ADAPTATION TO CHANGE LOAD CHARECTERISTICS YES YES YES YES
POWER CONTROL MANUAL AUTO AUTO AUTO
LOAD SENSED SELF TUNING YES YES YES
SIZE (mm) W-225
B-500
H-430
W-530
B-640
H-1110
W-620
B-725
H-1370
W-1000
B-1090
H-1675
INPUT POWER RANGE SINGLE PHASE
230V/50Hz.
THREE PHASE
230V/50Hz
THREE PHASE
440V/50Hz
THREE PHASE
440V/50Hz
